J03092+7601
SDSSJ030914.26+760152.0 · Culpan knownhsd
χ²/N = 0.99
Spectrum
shaded: the intervals the fit used · │ a cancelled pixeldrag on either panel to zoom · dbl-click or Esc to reset · arrows to pan
The whole reduced spectrum above, the region marked on it below. Shaded bands are the intervals the fit used; a tick under the axis marks a pixel the rejection mask cancelled.
Line-profile fit — Bamberg
Line-profile fit — uli
Results and provenance
Fit — Bamberg
| Teff [K] | 21243 ± 248 |
| log g | 4.802 ± 0.034 |
| log n(He)/n(H) | -0.944 ± 0.038 |
| reduced χ² | 0.989 over 659 points |
| radial velocity | -19.0 km s−1 |
| resolution (FWHM) | 2.00 Å |
| lines fitted | 13 |
| grids | HE-0.041.fits HE-0.125.fits HE-0.300.fits HE-0.550.fits +9 more |
| fitted | 04/09/2026 19:07:25 |
Fit — uli
| Teff [K] | 21548 ± 243 |
| log g | 4.736 ± 0.034 |
| log n(He)/n(H) | -0.964 ± 0.050 |
| reduced χ² | 0.970 over 659 points |
| radial velocity | -19.0 km s−1 |
| resolution (FWHM) | 2.00 Å |
| lines fitted | 13 |
| grids | h909.grid h97.grid h99.grid h999.grid |
| settled | outside the grid |
| fitted | 04/09/2026 18:34:40 |
Observation
| cosmic rays | 4 pixels cancelled |
| source file | spec-102084-60220-63050394815076437.fits |
Gaia astrometry
| Gaia DR3 source | 548172280923344000 |
| parallax [mas] | 0.7157 ± 0.0176 |
| G | 14.285 |
| Gabs | 3.634 |
| μα [mas/yr] | 1.754 |
| μδ [mas/yr] | -1.392 |
| l, b | 131.074, 15.387 |
Published (Culpan et al. 2022)
| class (Culpan) | sd |
| class (SIMBAD) | sd |
Fitted lines
| line | λ [Å] | shift [Å] | continuum at | ±avg | fitted over |
| Hβ | 4861.32 | -0.31 | -40.0, 40.0 | 5.0 | -45.0, 45.0 |
| Hγ | 4340.46 | -0.28 | -40.0, 36.8 | 4.5 | -43.0, 43.0 |
| Hδ | 4101.73 | -0.26 | -40.0, 31.6 | 4.2 | -43.0, 43.0 |
| Hε | 3970.07 | -0.25 | -28.0, 30.0 | 4.1 | -30.0, 35.0 |
| Hζ | 3889.05 | -0.25 | -20.0, 26.2 | 4.0 | -31.8, 32.0 |
| Hη | 3835.38 | -0.24 | -20.0, 14.6 | 4.0 | -20.7, 21.8 |
| Hθ | 3797.90 | -0.24 | -16.0, 16.0 | 3.9 | -15.6, 16.7 |
| Hι | 3770.63 | -0.24 | -13.0, 13.0 | 3.9 | -11.7, 11.6 |
| Hκ | 3750.15 | -0.24 | -10.0, 10.0 | 3.9 | -7.4, 8.7 |
| He II 4686 | 4685.70 | -0.30 | -11.9, 11.9 | 4.9 | -15.0, 13.8 |
| He I 4472 | 4471.60 | -0.28 | -15.0, 15.0 | 4.6 | -15.0, 15.0 |
| He I 4026 | 4026.29 | -0.26 | -24.2, 15.0 | 4.2 | -15.0, 15.0 |
| He I 4922 | 4921.93 | -0.31 | -15.0, 15.0 | 5.1 | -15.0, 15.0 |
Spectral energy distribution
Teff 21243 K · log g 4.802 · E(44−55) 0.280 · χ²r 0.25 over 43 bands
distance 1397 pc · parallax 0.7200 ± 0.0200 mas (3%) · R 0.4923 +0.0133 −0.0126 R☉ · M 0.560 +0.076 −0.067 M☉ — above the 0.47 canonical mass · L 44.5 +3.0 −2.8 L☉
Photometry against the model, with the residual beneath it in units of the error. The horizontal bar on each point is the passband, not an error; a hollow point was not fitted and the tooltip says why. Drag a box to zoom, double-click or Esc to come back out.
