J09294-0148
SDSSJ092924.84-014855.2 · Culpan knownhsd
χ²/N = 0.96
Spectrum
shaded: the intervals the fit used · │ a cancelled pixeldrag on either panel to zoom · dbl-click or Esc to reset · arrows to pan
The whole reduced spectrum above, the region marked on it below. Shaded bands are the intervals the fit used; a tick under the axis marks a pixel the rejection mask cancelled.
Line-profile fit — Bamberg
Line-profile fit — uli
Results and provenance
Fit — Bamberg
| Teff [K] | 19910 ± 285 |
| log g | 4.693 ± 0.035 |
| log n(He)/n(H) | -2.159 ± 0.077 |
| reduced χ² | 0.962 over 656 points |
| radial velocity | -150.0 km s−1 |
| resolution (FWHM) | 2.00 Å |
| lines fitted | 13 |
| grids | HE-0.041.fits HE-0.125.fits HE-0.300.fits HE-0.550.fits +9 more |
| fitted | 04/09/2026 19:08:09 |
Fit — uli
| Teff [K] | 20114 ± 167 |
| log g | 4.591 ± 0.026 |
| log n(He)/n(H) | -2.152 ± 0.094 |
| reduced χ² | 0.963 over 656 points |
| radial velocity | -150.0 km s−1 |
| resolution (FWHM) | 2.00 Å |
| lines fitted | 13 |
| grids | h909.grid h97.grid h99.grid h999.grid |
| settled | outside the grid |
| fitted | 04/09/2026 18:35:11 |
Observation
| source file | spec-3781-55243-0040.fits |
Gaia astrometry
| Gaia DR3 source | 3838107608930614400 |
| parallax [mas] | 0.1409 ± 0.0767 |
| G | 16.997 |
| μα [mas/yr] | -1.152 |
| μδ [mas/yr] | -2.793 |
| l, b | 235.341, 33.456 |
Published (Culpan et al. 2022)
| class (Culpan) | sdB |
| class (SIMBAD) | sdB |
Fitted lines
| line | λ [Å] | shift [Å] | continuum at | ±avg | fitted over |
| Hβ | 4861.32 | -2.43 | -40.0, 40.0 | 5.0 | -45.0, 45.0 |
| Hγ | 4340.46 | -2.17 | -40.0, 36.8 | 4.5 | -43.0, 43.0 |
| Hδ | 4101.73 | -2.05 | -40.0, 31.6 | 4.2 | -43.0, 43.0 |
| Hε | 3970.07 | -1.99 | -28.0, 30.0 | 4.1 | -30.0, 35.0 |
| Hζ | 3889.05 | -1.95 | -20.0, 26.2 | 4.0 | -31.8, 32.0 |
| Hη | 3835.38 | -1.92 | -20.0, 14.6 | 4.0 | -20.7, 21.8 |
| Hθ | 3797.90 | -1.90 | -16.0, 16.0 | 3.9 | -15.6, 16.7 |
| Hι | 3770.63 | -1.89 | -13.0, 13.0 | 3.9 | -11.7, 11.6 |
| Hκ | 3750.15 | -1.88 | -10.0, 10.0 | 3.9 | -7.4, 8.7 |
| He II 4686 | 4685.70 | -2.34 | -11.9, 11.9 | 4.9 | -15.0, 13.8 |
| He I 4472 | 4471.60 | -2.24 | -15.0, 15.0 | 4.6 | -15.0, 15.0 |
| He I 4026 | 4026.29 | -2.01 | -24.2, 15.0 | 4.2 | -15.0, 15.0 |
| He I 4922 | 4921.93 | -2.46 | -15.0, 15.0 | 5.1 | -15.0, 15.0 |
Spectral energy distribution
Teff 19910 K · log g 4.693 · E(44−55) 0.064 · χ²r 0.20 over 35 bands
distance 7097 pc · parallax 0.1400 ± 0.0800 mas (57%) · R 0.5437 +0.5380 −0.1855 R☉ · M 0.534 +1.578 −0.305 M☉ · L 41.9 +124.0 −23.8 L☉
Photometry against the model, with the residual beneath it in units of the error. The horizontal bar on each point is the passband, not an error; a hollow point was not fitted and the tooltip says why. Drag a box to zoom, double-click or Esc to come back out.
